a powerful & versatile horizontal bending machine
Features
Bending horizontally on a flat bed has two main advantages:
- your part will always be perfect since you lay on a flat surface instead of referencing against two small fingers
- you can bend a close loop (like a 9 shaped part), hence saving time and possibly also a welding operation
The Digibend takes advantage of this and with its unique features goes beyond.
The Digibend table is a machined out of a single monoblock of Meehanite® 700N/mm2 (no welding points), the cylinder is completely embraced in the structure and the RAM is guided in all its stroke in order to be able to maintain the highest accuracy even in the high tonnage demanding applications. The strong structure combined with the unique control system and the specifically designed hydraulics ensure the repeatability accuracy (0,05 mm) even after thousands of bends.
The flexible and strong design of the Digibend table (with antimarking treatment) together with the easy to use control system (2 axis CNC controlled) allows any customer to create their own custom tools for special applications.
Specifications
-Max Pressure: 200kN
-Max Stroke: 195 mm
-Max Working Speed: 9.6 mm/sec
-Min Working Speed: 4.8 mm/sec
-Return Speed: 48 mm/sec
-Average Working Speed: 28.8 mm/sec
-Storable Programs: 255
-Sequence of Storable Programs: 50
-Number of Bends for Each Sequence: 16
-Working Table Dimensions: 480mmx1060mmx925mm
-Working Height: 925 mm
-Oil Tank Capacity: 40 lt
-Motor: 3-2 HP
-Weight: 340 kg
-Overall dimensions: 580mmx1060mmx1150mm
